High Reliability and Stability 1X8 Fiber Optic PLC Splitter SC/APC 1X8 GEPON PLC Splitter

  • 1
  • 2
  • 3

Brand Name : Gezhi or OEM

Model Number : PLC-1X8-AA

Certification : CE RoHS,ISO9001

Place of Origin : China

MOQ : 1 pieces

Price : USD >= 1 pieces $2.5

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 1000 Piece/Pieces per Day

Packaging Details : inner box,Carton

Network : TCP, Ip, POE, GPRS, wifi

Port : 1x8

Wavelength : 1260-1650nm

Fiber Collector : SC/APC, SC/UPC, FC/APC, etc.

Application : GEPON

Contact Now

Product descriptiion

High Reliability and Stability 1X8 Fibra Optica PLC Splitter

Planar lightwave circuit (PLC) splitter is a type of optical power management device that is fabricated using silica optical waveguide technology. It features small size, high reliability, wide operating wavelength range and good channel-to-channel uniformity, and is widely used in PON networks to realize optical signal power splitting. Gezhi Photonics provides whole series of 1xN and 2xN splitter products that are tailored for specific applications. All products meet GR-1209-CORE-2001 and GR-1221-CORE-1999 requirements.

High Reliability and Stability 1X8 Fiber Optic PLC Splitter SC/APC 1X8 GEPON PLC SplitterHigh Reliability and Stability 1X8 Fiber Optic PLC Splitter SC/APC 1X8 GEPON PLC SplitterHigh Reliability and Stability 1X8 Fiber Optic PLC Splitter SC/APC 1X8 GEPON PLC Splitter

Features

♦ Good channel-to-channel uniformity

♦ Wide Operating Wavelength: From 1260nm to 1650nm

♦ Wide Operating Temperature: From -40℃ to 85℃

♦ High Reliability and Stability

Compliance

♦ Telcordia GR-1209-CORE-2001

♦ Telcordia GR-1221-CORE-1999

♦ RoHS

Technical Paremeter

Parameter 1xN PLC Splitter Specification
Operating Wavelength (nm) 1260 ~ 1650
Type 1x2 1x4 1x8 1x16 1x32 1x64
Insertion Loss (dB) Typical 3.6 6.8 10.0 13.0 16.0 19.5
Max 3.8 7.1 10.3 13.5 16.5 20.5
Uniformity (dB) Typical 0.4 0.5 0.5 1.0 1.0 2.5
Max 0.6 0.6 0.8 1.2 1.5 2.5
PDL(dB)Max Typical 0.1 0.1 0.1 0.2 0.2 0.2
Max 0.15 0.15 0.25 0.3 0.3 0.3

Wavelength

department loss(dB)

 Typical 0.1 0.1 0.1 0.3 0.4 0.7
Max 0.2 0.3 0.4 0.6 0.8 1.0

Temperature

department loss

 Typical 0.3 0.3 0.3 0.4 0.4 0.4
Max 0.5 0.5 0.5 0.5 0.5 0.5
Directivity (dB) Min 55
Return Loss (dB) Min 55(50)
Operating Temperature (°C) -40~ +85
Storage Temperature (°C) -40 ~ +85
Fiber length 1m or Customized
Fiber Type G657A
Connector Type Customized
PLC Splitter Bare Fiber (mm) 4x4x40 4x4x40 4x4x40 4x7x50 4x7x50 4x12x60
PLC Splitter Blockless (mm) 4x4x40 4x7x60 4x7x60 4x12x60 6x20x80 6x40x100
PLC Splitter Module (mm) 100x80x10 100x80x10 100x80x10 120x80x18 120x80x18 141x115x18
PLC-splitter-rack-mountable(mm) 19’1U 2U Rack-Mount Box, LGX Box, ODF Box

Ordering information

GP XXX XX XX XX XX XX

Port

Configrition

 Module type Cable type Fiber length Input connector

Output

connector

G=Gezhi

P=PLC

102=1x2

104=1x4

108=1x8

116=1x16

132=1x32

164=1x64

204=2x4

208=2x8

216=2x16

232=2x32

264=2x64

BF=Bare Fiber

BL=Blockless

MO=Module

LG=LGX Box

RM=Rack Mount

CB=Cassette Box

XX=Customized

00=none

09=900um

Loose tube

20=2.0mm

30=3.0mm

05=0.5m

10=1.0m

15=1.5m

30=3.0m

40=4.0m

50=5.0m

......

0=none

1=LC/UPC

2=LC/APC

3=SC/UPC

4=SC/APC

5=FC/UPC

6=FC/APC

7=LC/APC

X=Customized

0=none

1=LC/UPC

2=LC/APC

3=SC/UPC

4=SC/APC

5=FC/UPC

6=FC/APC

7=LC/APC

X=Customized

Shipping

High Reliability and Stability 1X8 Fiber Optic PLC Splitter SC/APC 1X8 GEPON PLC Splitter

Q1:Can I have a sample order? What is your MOQ?

A1:Sample order is welcome to test and check quality. We don't MOQ, 1pcs sample is available. Also Mixed samples are acceptable.
Q2: What's the Lead time?
A2: The normal lead time is about 1week, For big quantity and special products. Please check lead time with our sales representative. But we keep stock for some products, could ship 1-3 days after receiving payment.
Q3: What are the payment terms?
A3: Payment term: T/T, Paypal, Western union,cash payment, ALI etc.
Q4: What is your warranty time
A4: 3 years' warranty.
Q5: Could I use our own logo, label and package?
A5: Yes, we could provide OEM service which according to your requirements, design products label, logo, PN, SN, package.
